Available for hire or rent from AAH Australia, the 10 m / 33 ft hybrid knuckle boom lift offers flexible operation with the option to run on battery power for quiet, low-emission performance or switch to diesel when extended duty cycles are required. Its articulating boom delivers excellent up-and-over reach, while the rotating jib provides industry-leading horizontal rotation alongside strong vertical access. Compact dimensions allow it to pass through standard doorways, navigate tight spaces, and work efficiently around obstacles—making it ideal for urban, indoor, and congested job sites.
Knuckle Boom Lift – Hybrid – 10m (33ft)
AAH has a range of knuckle boom lifts available for immediate hire / rent, with branch locations in Sydney, Melbourne, Brisbane and Perth. Contact us to discuss your requirements.
MACHINE SPECIFICATIONS:
- Platform Height – 10.20m / 33ft
- Working Height – 12.20m / 40ft
- Horizontal reach – 6.10m
- Up & Over Height – 4.00m
- Stowed Height – 1.95m
- Stowed Length – 4.10m
- Unit Width – 1.60m
- Platform Size – 1.1 x 0.65m
- Max Lift Capacity – 200kg
- Unit Weight – 3330kg
- Suitable Terrain – Rough
- Click Here To Download Spec Sheet
- Measurements are approximate; images are for illustration only.
Additional information
| Platform Height | 10.20m / 33ft |
|---|---|
| Working Height | 12.20 / 41ft |
| Horizontal Reach | 6.10m |
| Up & Over Height | 4.00m |
| Max Lift Capacity | 200kg |
| Platform Size | 1.1 x 0.65m |
| Stowed Height | 1.95m |
| Stowed Length | 4.10m |
| Unit Width | 1.60m |
| Unit Weight | 3330kg |
| Max Lift Capacity | 200 to 250kg |
| Suitable Terrain | Smooth, Rough, Smooth/Rough |
| Power Type | Electric, Diesel, Hybrid |
